SSL/TLS Protocols: A Practical Guide to Secure Web Communication

Key takeaways

• SSL and TLS are cryptographic protocols that encrypt communication between devices, servers, or applications across a network or the internet.

• To enable TLS for Windows 7, you’ll need to install Service Pack 1 and Windows Update KB3140245, then either manually update the DefaultSecureProtocols registry subkey or use Microsoft's “Easy Fix.”

• TLS evolved from SSL after the Internet Engineering Task Force (IETF) standardized and enhanced the protocol in 1999 to address SSL's security vulnerabilities, making TLS the modern standard, although the two terms are still often used interchangeably.

SSL/TLS works by using a TLS handshake to verify the server's identity, agree on encryption algorithms, generate shared session keys, and encrypt all subsequent communication. Explore SSL/TLS’s working mechanisms in depth, as well as their applications in improving web security.

If you’re ready to start building expertise in network security, enroll in the Akamai Network Engineering Professional Certificate. You’ll have the opportunity to learn about networking technologies like TCP/IP, securing remote access systems, managing network security incidents, and more in as little as three months. Upon completion, you’ll have earned a career certificate for your resume.

What are the SSL and TLS protocols?

Secure Sockets Layer (SSL) and Transport Layer Security (TLS) are cryptographic protocols that create a secure, encrypted communication channel between two devices, servers, or applications over a network or the internet. By protecting transmitted data from tampering or unauthorized viewing, SSL/TLS protocols form the backbone of secure web browsing, protecting sensitive information such as passwords and credit card numbers entered on a website.

SSL is the older version of the technology released by Netscape in 1995; it has since been deprecated, and modern networks no longer use it [1]. The Internet Engineering Task Force (IETF) standardized SSL in 1996, and in 1999, the IETF improved its security and renamed it TLS, as Netscape no longer developed it. TLS is the current version of the protocol, although people use the terms SSL and TLS interchangeably [2].

Why did TLS replace SSL?

The primary reason for replacing SSL was its security vulnerabilities. For example, the BEAST (Browser Exploit Against SSL/TLS) attack in 2011 exposed the limitations of SSL’s cipher block chaining encryption, allowing hackers to intercept and decrypt sensitive transaction data. Additionally, Google researchers discovered a major vulnerability in SSL 3.0 in 2014, called POODLE (Padding Oracle On Downgraded Legacy Encryption). The POODLE attack forces web browsers to use the SSL protocol instead of TLS, allowing hackers to exploit known weaknesses in SSL 3.0 to steal secure data.

These issues accelerated the move to TLS, which fixes many of SSL’s issues by using stronger, modern encryption algorithms; verifying both client and server sides through TLS certificates; using digital signatures to detect any data modifications; and speeding up the handshake process by reducing the number of steps and cipher suites [3].

How do SSL/TLS protocols work?

The TLS protocol comprises two layers: the TLS handshake protocol, which securely connects the client device and web server, and the TLS record protocol, which secures the data for transmission using ciphers and encryption keys. These layers operate above the TCP/IP transport layer, which standardizes data transmission over the internet [2].

Encryption keys

TLS uses cryptographic keys, strings of random letters and numbers, to secure the communication between the client device and web server. For TLS, you’ll generally use two types of encryption keys [2]:

• Symmetric encryption: Both parties receive a single key that performs both encryption and decryption. In other words, the sender encrypts the data using a secret key, and the receiver decrypts the information using the same key. This system is ideal for securely sending large amounts of data because it's fast and efficient, with low computational overhead. However, it's important to ensure the secret key is securely exchanged between parties. Examples of symmetric encryption include AES and Blowfish.

• Asymmetric encryption: A pair of mathematically linked public-private keys encrypt/decrypt data. You'll find the public key in the TLS certificate, while only the website owner knows the private key. You can only decrypt data encrypted with a public key with the corresponding private key, so it remains secure even if malicious actors get hold of the public key. This system offers higher levels of security and is ideal for open networks and digital identity management. However, it can be slower and more resource-intensive. Examples of asymmetric encryption include RSA and ECC.

Read more: What Is Quantum Safe Encryption?

What are SSL/TLS certificates and cipher suites?

A cipher suite is a collection of encryption protocols that defines algorithms for key exchange, validation, encryption, and message authentication to ensure data integrity and confidentiality.

An SSL/TLS certificate is a digital document installed on the origin server to verify the website's legitimacy. Provided by trusted Certificate Authorities (CAs), digital certificates attest to the ownership of a public key and provide information about the domain owner, establishing trust in the website and indicating its authenticity to users [1].

TLS handshake

The TLS handshake is a sequence of steps that authenticates the server's digital certificate and establishes a secure connection between the client and the server. During the handshake, both parties decide which TLS version to use, specify the necessary cipher suites, verify each other's legitimacy through digital certificates, and generate and exchange session keys to encrypt messages after the handshake [1].

The TLS handshake generally involves the following steps [2]:

1. The client requests access to a page by sending the “hello” message to the server, along with the TLS version, a list of supported cipher suites, and a random string.

2. The server responds with its own “hello” message, selected cipher suites, and another random string. The server also sends a copy of its digital certificate that includes the public key.

3. The client checks if a trusted CA issued the certificate to ensure the server’s authenticity.

4. If legitimate, the client generates another random string called the premaster secret key, encrypts it with the server’s public key, and transmits it to the server for decryption with its private key.

5. After the server decrypts the secret key, both parties use this secret key to generate a session key that should match.

6. Both sides send a “finished” message encrypted with the session key, and if both sides can decrypt it, the handshake is complete.

7. This establishes a secure connection, and after this point, the session key, which is a symmetric key, encrypts all transmissions between the client and server.

TLS record layer

The record layer secures and verifies the integrity of the transmitted data using the agreed-upon cipher suites and session keys created during the handshake. The record layer fragments outgoing messages into blocks and reassembles incoming messages, optionally compresses or decompresses messages, applies the message authentication code (MAC) created from the session key, and encrypts outgoing messages and decrypts incoming messages [2].

Modern TLS standards

TLS 1.0 was the immediate successor to SSL 3.0; although it provided improvements over SSL 3.0, such as stronger encryption algorithms and MACs, it still had security vulnerabilities. TLS 1.1 improved upon TLS 1.0 by adding defenses against padding oracle attacks and cipher block chaining. However, it was soon replaced with newer TLS versions [4]:

TLS 1.2

Released in 2008, TLS 1.2 is still one of the most used versions. It introduced significant security improvements over TLS 1.1, including support for authenticated encryption, newer cipher suites, and better resistance to cyberattacks [2].

TLS 1.3

The most recent version and preferred protocol for securing network connections, TLS 1.3 offers better performance and privacy, faster connection times, and increased security through forward secrecy, where compromised public or private keys still ensure the security of the unique session key [2].

How does HTTPS use SSL/TLS?

Hypertext Transfer Protocol (HTTP) is a set of communication rules for sending data over a network, and HTTPS encrypts this data using the SSL/TLS protocol. The 'S' in HTTPS stands for 'secure.' HTTPS secures website traffic by encrypting all HTTP requests and responses using session keys generated during the TLS handshake between the browser and the server, ensuring that anyone observing the session can only see random strings. In this way, SSL/TLS protects HTTP sites from interception and man-in-the-middle attacks, increasing the website's authenticity and trustworthiness.

HTTPS websites have an SSL/TLS certificate from a recognized Certificate Authority that verifies their legitimacy. You can check if a website is secure by looking at the URL: a secure site will show https:// instead of http://, and a padlock icon will appear next to the URL bar. If you click the padlock icon, you can see whether the certificate is valid, the name of the issuing authority, and the website's corporate name [5].

What are the practical applications of SSL/TLS protocols?

Encryption:

• protects data exchanged between clients and servers

• Authentication: digital certificates prevent man-in-the-middle attacks

• Integrity: MAC comparison detects tampering

• Compliance: supports PCI-DSS and GDPR requirements.

For these reasons, SSL/TLS is fundamental to securing devices, servers, and applications connected to the web. Some of the internet applications that SSL/TLS security can help protect include:

• Web browsing: SSL/TLS keeps sensitive data, like login details, personal identifying information, and payment and transaction data, secure against data breaches, an important aspect of building customer trust in e-commerce websites and complying with regulations in industries like health care and finance.

• Email: Many cloud-based email service providers leverage SSL/TLS to encrypt messages during transit from email servers to clients, preventing unauthorized access.

• Voice over IP (VoIP): Internet-based voice calls may be exposed to eavesdropping or manipulation by hackers. Using TLS to create an encrypted channel between the client and server prevents tampering with call setup details and the exposure of participant details, such as phone numbers.

• IoT devices: IoT (Internet of Things) devices use mutual TLS (mTLS), where both the client and server verify each other’s identity during the handshake, to secure client-client and client-server communications. Since IoT devices often operate in unreliable environments and handle sensitive data, they may be vulnerable to eavesdropping, tampering, impersonation, and password hacking. mTLS uses digital certificate-based authentication to ensure both the sender and receiver are legitimate, reducing the risk of data exposure.

• Search engine optimization (SEO): Another benefit of TLS security is higher search engine rankings. Google and other search engines prioritize HTTPS websites in search results over HTTP websites, even labeling them as “not secure” to discourage users from visiting such pages. Hence, having a TLS certificate can help websites boost visibility and increase traffic.

How to enable TLS and SSL protocols in Windows 7?

Windows 7 supports TLS versions 1.1 and 1.2, but these are disabled by default. To enable it, you’ll need to install Service Pack 1 for Windows 7 from Microsoft and Windows Update KB3140245, and then update the registry. You can update the registry manually using the DefaultSecureProtocols registry subkey, or download Microsoft’s “Easy fix” to set the security protocol to TLS 1.2 by default.

How to learn about SSL/TLS protocols

To build your expertise in SSL/TLS protocols;

1. Start by learning about the different types of encryption and cryptographic algorithms. You can leverage structured learning courses from reputable organizations like Microsoft or explore challenges and puzzles on platforms like CryptoHack to learn in a more hands-on manner.

2. Study public key infrastructure (PKI) and how public and private keys work, laying a foundation for understanding SSL/TLS. You can use online guides from platforms such as IBM or Keyfactor to better understand certifying authorities and digital certificates.

3. Learning about TLS concepts like the handshake, cipher suites, and TLS versions. Leverage books like “Bulletproof SSL and TLS” by Ivan Ristic and platforms like Cloudflare Learning Center to gain a thorough theoretical understanding of these essential concepts.

4. Pursue certifications and training programs for more in-depth knowledge. For example, in DigiCert’s Digital Trust Professional certification program, you’ll complete courses on PKI, TLS, Domain Name System (DNS), and more.

If you prefer to learn online, you can begin by gaining a holistic understanding of web security, potential threats, and cryptography through a self-paced course like the Cisco Cybersecurity Operations Fundamentals Specialization.
